Model |
BC6050 |
BC6063/BC6066 |
BC6085 |
|
|
Max.shapping length(mm) |
500 |
650 |
630/660 |
850 |
|
|
Max.range of the borizontal movement of the table(mm) |
525 |
630 |
385 |
400 |
|
|
Max.distance between the ram bottom and table(mm) |
370 |
380 |
630 |
710 |
|
|
Max.length of the vertical movement of table(mm) |
270 |
315 |
360 |
360 |
|
|
Dimensions of table top(L×W)(mm) |
440×360 |
630×400 |
630×400/660×400 |
800×450 |
|
|
Max. stroke length of the toolhead(mm) |
120 |
120 |
120 |
160 |
|
|
Max.swivel angle of the toolhead(°) |
±60° |
±60° |
±60° |
±60° |
|
|
Max.section of tool(W×T)(mm) |
20×30 |
20×30 |
20×30 |
20×30 |
|
|
Number of ram reciprocation per minute(NO/min) |
14-80 |
14-80 |
14、20、28、40、56、80 |
17、24、35、50、70、100 |
|
|
Range of table feed |
Horizontal |
0.2-0.25 |
0.2-0.25 |
0.2~2.5 |
0.2~2.5 |
|
|
Vertical(mm/recip) |
0.08-1 |
0.08-1 |
0.08~1.00 |
0.08~1.00 |
|
|
Speed of rapid travel of table |
Horizontal |
0.95 |
0.95 |
|
1.2 |
|
|
Vertical |
0.38 |
0.38 |
0.58 |
|
|
width of the T-slot for center positioning(mm) |
18 |
18 |
18 |
22 |
|
|
Power of the main motor(kw) |
3 |
3 |
3 |
5.5 |
|
|
N.W/G.W(kg) |
1650 |
2200 |
1750/1870 |
2950×1325×1693 |
|
|
1800/1920 |
|
|
Overall dimensions(L×W×H)(mm) |
2160×1070×1194 |
2382×1210×1504 |
2342×1225×1480 |
2940/3090 |
|
|
2357×1225×1480 |
|
