Item Unit Y27K-315 Y27K-500 Y27K-500A Y27K-630 Y27K-630A Y27K-800 Y27K-1000 Y27K-1250 Y27K-1600 Y27K-2000 Nominal Pressure KN 3150 5000 5000 6300 6300 8000 10000 12500 16000 20000 Back Stroke Pressure KN 600 550 550 600 600 800 1000 1250 1500 1700 Force of Hydraulic Cushion KN 630 2000 2000 2000 2000 2500 3000 4000 4000 5000 Stroke Length mm 800 900 1000 900 1000 1100 1100 1200 1300 1300 Stroke of Hydraulic Cushion mm 300 350 350 400 400 400 400 450 450 450 Max. Daylight mm 1250 1500 1600 1500 1600 1800 1800 2000 2000 2000 Slide Speed Idle Stroke mm/S 120 250 250 250 250 250 300 300 300 300 工作Pressing mm/S 6-10 10-20 10-20 10-20 10-20 10-20 10-20 10-25 10-25 10-25 Return mm/S 60 200 200 200 200 200 250 250 250 250 Ejecting Speed Push out mm/S 50 90 90 60-90 60-90 60-90 60-90 60-90 60-90 50-60 Return mm/S 120 120 120 120 120 120 120 110 120 100 Available Table Area L.R. mm 1260 2000 2800 2500 3000 3600 3600 4500 5000 5200 F.B. mm 1120 1200 1600 1800 1800 2400 2400 2600 2600 2600 Movable Bed Overload T - - 15 15 20 20 30 40 50 50 Available Size of Hydraulic Cushion L.R. mm 650 1200 2000 1750 2900 2900 2900 3800 4250 4250 F.B. mm 650 750 1100 1100 1700 1700 1700 1750 1750 1750 Overall Dimension L.R. mm 2400 3300 5000 4400 4400 5390 5390 5500 6800 5620 F.B. mm 1800 2000 3300 2700 2700 3050 3050 3100 3150 3200 Above Ground mm 5200 6500 6500 6600 6700 6900 7300 7800 8000 7800 Power of Motor kW 22 60 60 88 88 104 104 141 228 293
