Model |
C41-25 |
C41-40 |
C41-75 |
|
Falling max. mass |
25 kg |
40 kg |
75 kg |
|
Max. blow energy |
275 J |
530 J |
1000 J |
|
Number of strokes (per min.) |
250 |
245 |
210 |
|
Distance from ram center to frame |
200 mm |
235 mm |
280 mm |
|
Motor power |
2.2 kw |
4 kw |
7.5 kw |
|
Max. square steel can be forged |
40X40 mm |
52X52 mm |
65X65 mm |
|
Max. round steel can be forged(Diameter) |
￠45 mm |
￠68 mm |
￠85 mm |
|
Mass of the anvil block |
250 kg |
400 kg |
850 kg |
|
Total mass of the hammer (kg) |
760 kg |
1350 kg |
2800 kg |
|
Package size (mm) |
|
1010*1000*1320 |
1010*1000*1320 |
1600x1000x1950 |
|
|
|
|
|
|
| |
|
|
|
|
|
